| 型号：WEICON BL 0.5 kg | 粘合材料类型：金属类 | 品牌：WEICON |
| 完全固化时间：24小时 | 耐温：-35 bis +180 °C | 颜色：blue |
WEICON Plastic Metal Ceramic BL 0,5 kg 陶瓷填补胶
Blue, brushable surface protection with extremely high wear and
abrasion resistance. Forms a smooth surface of low friction which
shows a high chemical resistance and which is used:
- for lining highly stressed pump cases
- as a wear protection for slide bearing, slides, funnels and pipes
- for repairing castings, valves and blower vanes
Purchase data
Item number 10400005
GTIN 4024596002886
Item features
Composition Epoxy resin mineral-filled
Specific Properties liquid, extremely wear resistant
Mixing ratio by weight % (Resin/Hardener) 100:10
Pot-life at +20°C (200 g preparation) 20 Min.
Density of the mixture 1,9 g/cm?
Viscosity of the mixture 40.000 mPa·s
Max. layer thickness per application 10 mm
Cure time mechanical loads 12 h
final hardness 24 h
Mean compressive strength (+25°C) acc. to DIN 53281-83 115 MPa
Mean tensile strength (+25°C) acc. to DIN 53281-83 25 MPa
Mean Flexural strength (+25°C) acc. to DIN 53281-83 98 MPa
Mean strength E-Modul (+25°C) acc. to DIN 53281-83 9.000 - 9.500 MPa
Shore D (+25°C) acc. to DIN 53281-83 88
Shrinkage 0,02 %
Thermoforming resistance 80 °C
Colour blue
Temperature resistance -35 bis +180 °C
